Passive Frequency Multiplier

Introduction

Passive frequency multiplier is essentially a circuit in which the output signal is equal to an integral multiple of the input signal frequency. The commonly used frequency multipliers are double frequency and triple frequency.

The main function of the frequency multiplier in the hand-held mobile phone is to raise the frequency of the carrier signal and make it work in the corresponding channel; At the same time, after frequency doubling, the frequency offset of FM signal can also be doubled, that is, the sensitivity of FM modulation is improved, which can reduce the requirements for amplification of modulated signal.

Another advantage of the acquisition frequency multiplier is that it can isolate the carrier main oscillator from the high-frequency amplifier, reduce the high-frequency parasitic coupling, reduce the generation of high-frequency self excitation, and improve the stability of the whole machine.

Principle

Passive frequency multiplier is a basic microwave circuit. The so-called frequency multiplier refers to the electronic equipment that can complete the frequency multiplication function of the input signal. In principle, all nonlinear devices can realize frequency doubling, and the frequency doubling realized by using the nonlinearity of semiconductor devices is called solid state frequency multiplier. When a sinusoidal signal is used to excite a nonlinear device, power will be generated at the harmonic frequency of the fundamental frequency. The function of frequency multiplier circuit is to effectively extract the required harmonic signal and suppress its fundamental frequency and unwanted harmonic.

Classification

Passive frequency doubler can be divided into two categories according to its working principle: one is nonlinear resistance frequency multiplier. This kind of frequency multiplier uses the nonlinear resistance effect of double junction transistor, field effect transistor or diode to convert the principle wave of large amplitude sine frequency multiplier into current pulse, and then select the required harmonic wave with frequency selection loop to complete frequency multiplication.

Another kind of nonlinear reactance frequency doubling is also called "parametric frequency doubling".

Application

●Communication System

●Test Equipment

●Radar&Warfars System

The passive frequency multiplier does not need DC power supply and is simple to use. It is widely used in microwave transceiver front-end.

As a means to obtain a highly stable signal source, frequency multiplier has its own characteristics and uses: It can reduce the main vibration frequency of electronic equipment, which is extremely important for communication machines and high-frequency electronic equipment with high operating frequency and strict stability requirements.

Packaging

To better ensure the safety of your goods, professional, environmentally friendly, convenient, and efficient packaging services will be provided. After receiving the goods, if you have any dissatisfaction or other issues, please contact us ASAP, and we will give you a fast response and reasonable solution.

Certificate

We implement TQM (Total Quality System) and SOP (Standard Operation Procedure) with ISO 9001:2017 certification, which assures a strong commitment to quality standards and customer satisfaction.

Shipping

We will send the goods to you by DHL, FEDEX, UPS, EMS, AIR, etc. Usually 7-15 working days after receiving your 100% payment. For bulk orders: 15-35 working days after receiving the deposit.
