Load Cell Transmitter

Introduction

Load cell transmitter is a transmitter that converts physical quantities into electrical signals and converts millivolt signal output sensors into standard DC signals through isolation and amplification. SMT process is usually adopted, which is designed and manufactured for resistance strain type signal sensors of industrial processes and is applicable to weighing sensors of different specifications.

Principle

The weighing transmitter can realize stable, reliable, and high-precision industrial weighing. It converts the weak signal (mV level) output by the weighing sensor into a readable weight signal through amplification, conversion, and other processing methods. The weighing result can be output through Ethernet, serial bus, Bluetooth, and other methods. It can also convert and output various specified industrial standard signals for other equipment to use according to requirements.

Purpose

The load cell transmitter is a high-performance weight transmitter with rail-mounted mode, which is used together with the strain sensor. The connected load cell signal can be converted into a stable signal for the PLC system or PC. The weighing transmitter is suitable for applications requiring local display or panel-based parameter setting.

The parameter setting and calibration of the instrument can be carried out on the panel by using keys, or by using the "deltaCOM" software based on the Windows environment. All the setting parameters can be stored in the computer. When replacing the transmitter, the parameters can be downloaded from the computer, which requires the use of the full version of deltaCOM software. The weighing transmitter provides two relay type output nodes with a response time of less than 20 milliseconds, which is particularly suitable for high-precision weight setpoint control applications.

The core of the weighing transmitter adopts the digital A/D converter designed by NOBEL Company, which provides stable, accurate, and fast signal conversion. It can communicate with PC/PLC system through standard RS-485 communication port and MODBUS RTU protocol. The field bus communication function can also be realized by using the module.

Features

1. 4-way fixed value output point logic can be customized.

2. The highest display resolution is 1/50000.

3. Perfect test self-checking function, which is convenient for customers to quickly find the fault point.

4. Digital calibration function.

5, a variety of communication protocols.

6. Wide power supply working range.

The weight transmitter has good stability, the output signal can be directly controlled by PLC, etc., and the installation is easy.

Application

Load cell transmitter is a kind of transmitter commonly used in the industrial weighing process, which is widely used in data acquisition, signal transmission conversion, distributed weighing control system, and batching system, mainly used in cement, concrete, glass, paper making, plastics, chemical industry, metallurgy, non-ferrous, cotton spinning, testing machine, and other industries to transmit, display and detect weighing level, weight load, tension, tension, and tension signals.

Certificate

We implement TQM (Total Quality System) and SOP (Standard Operation Procedure) with ISO 9001:2017 certification, which assures a strong commitment to quality standards and customer satisfaction.

Delivery

We will send the goods to you by DHL, FEDEX, UPS, EMS, AIR, etc. Usually 7-15 working days after receiving your 100% payment. For bulk orders: 15-35 working days after receiving the deposit.

Our service

Service standards: We are committed to providing a high-quality and responsive service to all clients.

OEM: Available for waveguide series.

Stable quality: implement the whole process of quality control, meticulous and strict inspection!

Reasonable price: Internal cost control, reducing expenses, benefiting customers!

Professional selection: more than 5 years of professional engineer selection, to provide you with alternative models of each factory, system solutions

Fast delivery: adequate stocking, shortened delivery time!

Door-to-door service: We usually send the parcel by DHL, EMS, TNT, etc. The tracking number will be sent to you after delivery. It usually takes 3~5working days to reach from our side to your side, which is very convenient for your business.
