Programmable Electronic Load

Introduction

An programmable electronic load is (or equivalent) an adjustable resistor. The actual products are generally composed of multiple electronic components, and the parameters are variable and controlled. Generally, it has a variety of power consumption load modes, such as constant resistance, constant current, constant voltage, constant power, and so on.

Principle

The principle is to control the conductivity of internal power MOSFETs or transistors (volume duty cycle size). Equipment that consumes electric energy by dissipating power of power transistors can accurately detect load voltage, accurately adjust load current, and simulate load short circuit. The simulated load is inductive resistive and capacitive, and the rise time of capacitive load current. The debugging and testing of general switching power supply is indispensable.

Effect

1. The programmable electronic load has perfect protection function. The protection function is divided into internal protection function and external protection function. Internal protection includes over-voltage protection, over-current protection, over-power protection, voltage reverse protection and over temperature protection. External protection includes over-current protection, over-power protection, load voltage protection and low-voltage protection.

2. Due to its special performance (providing a powerful test environment to meet different external needs), it occupies a large market in electronic instruments and meters, mainly applicable to various power supplies, batteries, adapters and occasions that need it for testing.

Characteristic

●Multiple measurement functions, which can measure voltage, current, power, peak value, average value, minimum value and maximum value

●Inputs and measurements can be viewed from the front panel.

●Independent channel work

●Built in pulse generator for continuous operation, pulse operation and triggering transient operation

●Support parallel configuration to realize trigger input and synchronous measurement

●Remote Programming Using SCPI Command Language

Application

Programmable electronic load is an instrument that consumes power supply current. Its application fields include power electronics and energy market. Advanced electronic loads can simulate complex and dynamically changing actual loads through stable and reliable inputs. It has four common working modes: CC, CV, CP and CR. Different types of loads can be selected according to the application requirements.

Certificate

We implement TQM (Total Quality System) and SOP (Standard Operation Procedure) with ISO 9001:2017 certification, which assures a strong commitment to quality standards and customer satisfaction.

Delivery

We will send the goods to you by DHL, FEDEX, UPS, EMS, AIR, etc. Usually 7-15 working days after receiving your 100% payment. For bulk orders: 15-35 working days after receiving the deposit.

Packaging

To better ensure the safety of your goods, professional, environmentally friendly, convenient, and efficient packaging services will be provided. After receiving the goods, if you have any dissatisfaction or other issues, please contact us ASAP, and we will give you a fast response and reasonable solution.
