Flexible Twistable Waveguide
Place of Origin: Shaanxi, China
Brand Name: EFine
Product name: Flexible-Twistable Waveguide
Type: Waveguide Components
Material: Copper, Aluminum, etc.
Usage: Communication Equipment
Feature: Easy Assembly
Model Number: OEM
Sample: Available
Product Description
The utility model relates to a Flexible Twistable Waveguide, which comprises a soft wave guide, a first flange and a protective sleeve; Including soft wave catheter; The inner wall of the soft wave catheter is provided with a corrugated part, and the outer side of the soft wave catheter is sleeved with a protective sleeve; The two ends of the soft wave conduit are respectively provided with a first flange and a second flange.
The flange plate and the Flexible Twistable Waveguide are fixed by welding, the four corners of the first flange plate are provided with the first screw hole, and the second flange plate is provided with the second screw hole corresponding to the first screw hole; One side of the first flange is provided with an annular groove; The utility model achieves the purpose of interlocking the two soft wave conduits through the cooperation between the annular protrusion, the annular groove and the adjusting bolt, and the interlocking fixation of the annular protrusion and the annular groove is more firm through the adjusting bolt. Compared with the traditional fixation method which only uses the flange bolt, the fixation method is more stable, so as to improve the service life.
Specification
Name | Waveguide High Power Termination | |
Specification | WR51-WR229(EIA)/BJ40-BJ180(GB)&Customized | |
Frequency(GHz) | 3.22-22.0 | |
VSWR | ≤1.15 | |
Insertion loss(dB) | 0.15 | |
Average power(Kw) | 2.5 | |
Peak power(Kw) | 500 | |
Material | Silver plated copper strip | |
Length(mm) | 50-3000 | |
Operation temperature(℃) | -55~ 85 | |
 |  |  |
Product Structure
The Flexible Twistable Waveguide is mainly composed of an inner conductor, a flange and an outer sheath. The inner conductor adopts an interlocking rectangular corrugated tube, which can be twisted at the same time to meet the needs of product installation in different directions; the flange is made of copper or Made of aluminum to meet the needs of different customers; the black silicone rubber sheath can provide protection for the work of the flexible waveguide and ensure the applicable performance of the flexible waveguide in various environments.
Feature
1. Small standing wave and low insertion loss;
2. Good flexibility, bendable and twistable;
3. Stable performance under bending and torsion.
Certificate
Shipping
Our Service
Service standards: We are committed to provide a high quality and responsive service to all clients.
OEM: Available for wave guide series.
Stable quality: implement the whole process of quality control, meticulous and strict inspection!
Reasonable price: Internal cost control, reducing expenses, benefiting customers!
Professional selection: more than 5 years of professional engineer selection, to provide you with alternative models of each factory, system solutions
Fast delivery: adequate stocking, shortened delivery time!
Door to door service: We usually send the parcel by DHL, EMS and TNT etc. The tracking number will be sent to you after delivery. It usually takes 3~5working days to reach from our side to your side, which is very convenient for your business.
