Compression Tension Load Cell
Place of Origin: Shaanxi, China
Brand Name: EFINE
Type: force sensor
Usage: measure tension and compression
Theory: Resistance Sensor
Range: 0.1~20(KN)
Rated output(mV/V): 2.0mV/V
Creep: 0.1%F.S/30min
Excitation, Recommended: 10VDC
Operating Temp.Range: -20~+65℃
Material: Stainless steel
Introduction
The Compression Tension Load Cell is an instrument for weighing weight, which has the characteristics of high precision, high reliability, and good stability. And easy to install and use, and suitable for hook scales, batching scales, packaging scales, electromechanical combined scales, and other occasions.
Param
Range (KG) | 0.1~20(KN) | ||
Comprehensive precision | 0.3%F.S | Sensitivity | 2.0mV/V |
Zero output | ±2%F.S | Creep | 0.1%F.S/30min |
Input resistance | 380±10Ω | Output resistance | 350±3Ω |
Temp. effect on zero | ±0.05%F.S/10℃ | Temp. effect on output | ±0.05%F.S/10℃ |
Operation temp.range | -20~+65℃ | Insulation resistance | ≥5000MΩ |
Safe Overload | 150%F.S | Excitation voltage | 10VDC |
Material | Stainless steel | Wiring | Input+: Red Input-:Black Output+:Green Output-:White |
Equipment characteristics
1. High precision
2. High reliability
3. High stability
4. Easy installation
5. Good interchangeability
6. Good impact resistance
Specification
Range | Size | ||||
KN | A | B | C | φ | M |
0.1~0.5 | 37.5 | 12 | 11.5 | 26 | M5 |
0.5~10 | 70 | 19 | 17 | 51 | M12 |
20 | 75 | 19 | 17 | 51 | M12 |
Application example
The electronic scale adopts Compression Tension Load Cell. Compared with ordinary pressure sensors, this sensor has high accuracy, low price and is not easy to be damaged, so it has a wide application prospect. The electronic scale can be used for batching and force measurement in factory production. It has the advantages of accurate measurement, high resolution, less damage, and low price.
Details show
1. Stainless steel material 17-4ph
2. Simple structure, good reliability, good interchangeability
3. Suitable for various batching scales, hopper scales, crane scales, etc.
Precautions
1. In order to prevent a large current from flowing through the Compression Tension Load Cell, a short circuit should be installed between the sensors to prevent accidental high current flow and burn them out. Even so, it is better to remove the pressure sensor when welding is required, and then install the load cell after a few works.
2. Moving parts such as balls should slide freely, and there should be no jamming, corrosion, etc.
3. The indenter should be made of 20mm thick chrome steel, the bottom surface of the indenter should be machined into an arc, its radius should be more than 3 times the radius of the sensor dome, and heat treatment should be performed to increase the hardness of the indenter. The fixing plate shall be made of 45# steel, its thickness shall not be less than 20mm, and the horizontality shall not exceed ±0.5° during installation.
