Waveguide Short
EFine Electronics offers a standard product line of waveguide short plates which provide high reflection short circuits for terminating all standard waveguides. Vector Telecom offers a cover, all-clear configuration as a standard product. Alternate materials and configurations are available upon request.
Place of Origin: Shaanxi, China，
Brand Name: EFine
Type: Slip Ring
Product name: Waveguide Short
Warranty: 1 Year
Sample: Available
Packing: Wooden Box
ifications】
|
Model No* |
Freq Range (GHz) |
VSWR (Min) |
Thickness (mm) |
WG Type |
Flange |
Material |
|
|
IEC |
EIA |
||||||
|
EF-3WS… |
0.32-0.49 |
60 |
23 |
R3 |
WR2300 |
FDP |
Al |
|
EF-4WS... |
0.35-0.53 |
60 |
23 |
R4 |
WR2100 |
FDP |
Al |
|
EF-5WS... |
0.41-0.62 |
60 |
18 |
R5 |
WR1800 |
FDP |
Al |
|
EF-6WS... |
0.49-0.75 |
60 |
18 |
R6 |
WR1500 |
FDP |
Al |
|
EF-8WS... |
0.64-0.98 |
60 |
14 |
R8 |
WR1150 |
FDP |
Al |
|
EF-9WS... |
0.75-1.15 |
60 |
14 |
R9 |
WR975 |
FDP |
Al |
|
EF-12WS... |
0.96-1.46 |
60 |
12 |
R12 |
WR770 |
FDP |
Al |
|
EF-14WS... |
1.13-1.73 |
60 |
12 |
R14 |
WR650 |
FDP |
Al |
|
EF-18WS... |
1.45-2.20 |
60 |
12 |
R18 |
WR510 |
FDP |
Al/Cu |
|
EF-22WS... |
1.72-2.61 |
60 |
10 |
R22 |
WR430 |
FDP |
Al/Cu |
|
EF-26WS... |
2.17-3.30 |
60 |
10 |
R26 |
WR340 |
FDP |
Al/Cu |
|
EF-32WS... |
2.60-3.95 |
60 |
8 |
R32 |
WR284 |
FDP |
Al/Cu |
|
EF-40WS... |
3.22-4.90 |
60 |
8 |
R40 |
WR229 |
FDP |
Al/Cu |
|
EF-48WS... |
3.94-5.99 |
60 |
7 |
R48 |
WR187 |
FDP |
Al/Cu |
|
EF-58WS... |
4.64-7.05 |
60 |
7 |
R58 |
WR159 |
FDP |
Al/Cu |
|
EF-70WS... |
5.38-8.17 |
60 |
7 |
R70 |
WR137 |
FDP |
Al/Cu |
|
EF-84WS... |
6.57-9.99 |
60 |
5 |
R84 |
WR112 |
FBP |
Al/Cu |
|
EF-100WS... |
8.20-12.40 |
60 |
5 |
R100 |
WR90 |
FBP |
Al/Cu |
|
EF-120WS... |
9.84-15.0 |
60 |
5 |
R120 |
WR75 |
FBP |
Al/Cu |
|
EF-140WS... |
11.9-18.0 |
60 |
5 |
R140 |
WR62 |
FBP |
Al/Cu |
|
EF-180WS... |
14.5-22.0 |
60 |
5 |
R180 |
WR51 |
FBP |
Al/Cu |
|
EF-220WS... |
17.6-26.7 |
60 |
4 |
R220 |
WR42 |
FBP |
Al/Cu |
|
EF-260WS... |
21.7-33.0 |
60 |
4 |
R260 |
WR34 |
FBP |
Al/Cu |
|
EF-320WS... |
26.3-40.0 |
60 |
4 |
R320 |
WR28 |
FBP |
Al/Cu |
|
EF-400WS... |
32.9-50.1 |
60 |
4 |
R400 |
WR22 |
FUGP |
Cu |
|
EF-500WS... |
39.2-59.6 |
60 |
4 |
R500 |
WR19 |
FUGP |
Cu |
|
EF-620WS... |
49.8-75.8 |
60 |
4 |
R620 |
WR15 |
FUGP |
Cu |
|
EF-740WS... |
60.5-91.9 |
60 |
4 |
R740 |
WR12 |
FUGP |
Cu |
|
EF-900WS... |
73.8-112 |
60 |
4 |
R900 |
WR10 |
FUGP |
Cu |
*Indicates Model Number. See Ordering Information for complete part number.
【Ordering Information】
▪ Flange type: Multiple types available - see EFine Electronics Flanges page
▪ Finish: Corrosion protection plus black top coat
