How does a pneumatic slip ring work?

Pneumatic slip ring, the transmission medium contains water, oil and other liquids, will also be called "liquid slip ring", pneumatic slip ring gas is compressed air, carbon monoxide and water vapor. Pneumatic slip rings are responsible for the connection of rotating objects, and power or signal transmission is carried out through pneumatic slip rings installed in the center of rotation of the equipment. The pneumatic slip ring is mainly composed of rotating and stationary parts. The stationary part is called the "stator" and the rotating part is called the "rotor". Since different types of pneumatic slip rings have different characteristics, it is especially important to choose pneumatic slip rings according to different uses.

Pneumatic slip rings and electric slip rings work on the same principle, both rotate 360 degrees to conduct electricity or transmit various signals. Generally speaking, it can carry out rotation cycle or rotation communication, mainly installed in the rotation center of the equipment, mainly composed of two parts: rotation and stationary. In the process of connecting the equipment, this product will rotate with this rotating structure, so it is also called a transmission bullet, and if some stationary parts are connected, it is also called a stator.

When the pneumatic slip ring rotates, which gas-liquid path will not interfere with each other, the slip ring is composed of a fixed stator and rotor contact, the stator brush wire contacts friction on the shell of the rotating metal ring, when the metal ring rotates, the current is conducted through the fixed brush wire to form a connected metal ring, and the slip ring is usually composed of multiple rings.

In the process of using pneumatic slip rings, its main function is to connect the rotating electrical interface, including some rotary joints of electrical appliances, whether fixed structure or rotary structure, can effectively transmit power or data signals. By sliding conductive parts and related operations, the frequency of the equipment can be effectively controlled.

Pneumatic slip rings can transmit compressed air, vacuum, hydraulic shaft, water, hot water, coolant, steam and other media. When rotated 360 degrees, it can transmit gas, power, signals and other media at the same time.
