Micro Load Cell

Introduction

The micro load cell is made of aluminum alloy or stainless steel and is of pressure division or tension-compression dual-use type. The diameter is small, the height is low, the diameter is 20cm, and the height is less than 10cm, which is equivalent to the size of a coin. It is convenient to use, with accurate force measurement and high accuracy. It is also called a button sensor, small compression sensor, micro force sensor, micro sensor, and imported micro load sensor.

It is applicable to force measurement in small spaces. The micro weighing sensor system is a new type of electronic weighing sensor developed based on the traditional resistance strain sensor, combined with modern microelectronic technology and microcomputer technology.

Structure

The miniature load cell comprises an analog sensor (resistance strain gauge) and a digital conversion module. The digital module is made of a highly integrated electronic circuit using SMT surface mount technology, mainly including an amplifier, A/D converter, microprocessor (CPU), memory, the interface circuit (RS485), and digital temperature sensor.

The sensor adopts a miniature precision design, steel integrated structure, and high protection performance. It is mainly used for occasions with limited space.

Working principle

The working principle of the micro load cell is to stick the resistance strain gauge on the elastic sensing element and then form an electric bridge appropriately to convert the object's mass into an electrical signal.

Advantages

The micro weighing sensor is a small load cell, which has the advantages of accurate measurement, easy maintenance, flexible use, high reliability, good stability, and convenient use. It has certain applications in many fields.

Application

The micro load cell is widely used in electronic pricing scales, platform scales, table scales, electronic belt scales, sorting scales, truck scales, dynamic track scales, large tonnage hopper scales, and other devices. Because of its small size, light weight, easy installation, and other characteristics, it is especially suitable for small-size occasions.

Certificate

We implement TQM (Total Quality System) and SOP (Standard Operation Procedure) with ISO 9001:2017 certification, which assures a strong commitment to quality standards and customer satisfaction.

Delivery

We will send the goods to you by DHL, FEDEX, UPS, EMS, AIR, etc. Usually 7-15 working days after receiving your 100% payment. For bulk orders: 15-35 working days after receiving the deposit.

Our Service

Service standards: We are committed to providing a high-quality and responsive service to all clients.

OEM: Available for waveguide series.

Stable quality: implement the whole process of quality control, meticulous and strict inspection!

Reasonable price: Internal cost control, reducing expenses, benefiting customers!

Professional selection: more than 5 years of professional engineer selection, to provide you with alternative models of each factory, system solutions

Fast delivery: adequate stocking, shortened delivery time!

Door-to-door service: We usually send the parcel by DHL, EMS, TNT, etc. The tracking number will be sent to you after delivery. It usually takes 3~5working days to reach from our side to your side, which is very convenient for your business.
