Two Half Style Slip Ring

Introduction

Two half style slip ring is different from ordinary conductive slip ring, is a separate conductive slip ring, the length of the conductive slip ring rotor can be changed arbitrarily according to customer requirements or the length of stator (shaft), suitable for a variety of types of conductive slip ring for rotor length requirements, reduce the production cost of conductive slip ring rotor. This kind of separate conductive slip ring has simple structure and easy assembly, which is suitable for the requirements of a variety of types of conductive slip ring for rotor length, especially suitable for mechanical equipment maintenance and replacement slip ring and other environments where the integral slip ring cannot be installed, or cannot be put in by the end, reducing the production cost of the conductive slip ring rotor.

Principle

The slip ring transmits energy and data between the two components, mainly consisting of a set of metal rings and corresponding brush wires. The working principle of the two half style slip ring is to make the metal ring in contact with the wire, in this process the brush part is stationary, the metal part rotates, and the wires of the brush and the conductive ring are in internal contact, electrically connected with the equipment on both sides of the slip ring. Therefore, one end of the wire and the stator of the slip ring are fixed, and the wire at one end rotates together with the rotor of the slip ring, which is equivalent to no winding.

Feature

Two-half slip rings, or can be called fiber brush slip rings, because fiber brush technology is applied in this design. In the case of complicated installation conditions, a separate type slip ring is designed for easy installation. It is different from the traditional design, the rotor and the stator are separated structures, and the design adopts carbon brush technology. Ease of maintenance, having silver inner contact material, compact size, long life and simple installation are the advantages of this type of slide.

Application

The two half style slip ring is mainly used in closed-circuit monitoring spherical heads, electrical testing equipment, manufacturing and processing control equipment, rotary workbenches, small winding machines, exhibition display equipment, aviation, military, instrumentation and medical equipment, magnetic transmission devices, processor-controlled devices, emergency lights, robots, radars, and more.

Certificate

We implement TQM (Total Quality System) and SOP (Standard Operation Procedure) with ISO 9001:2017 certification, which assures a strong commitment to quality standards and customer satisfaction.

Delivery

We will send the goods to you by DHL, FEDEX, UPS, EMS, AIR, etc. Usually 7-15 working days after receiving your 100% payment. For bulk orders: 15-35 working days after receiving the deposit.

Packaging

To better ensure the safety of your goods, professional, environmentally friendly, convenient, and efficient packaging services will be provided. After receiving the goods, if you have any dissatisfaction or other issues, please contact us ASAP, and we will give you a fast response and reasonable solution.
